Under Selected Component, drag a 15-pin SATA power connector to the power port on the optical drive. Connect the optical drive as follows: Above the computer, select Drive Bays to switch to the Drive Bays view for the computer. Under Selected Component, drag a 15-pin SATA power connector to the power port on the third hard drive. Under Selected Component, drag a 15-pin SATA power connector to the power port on the second hard drive. Connect the SATA hard drives as follows: Under Selected Component, drag a 15-pin SATA power connector to the power port on the hard drive.

Under Selected Component, drag the 8-pin CPU power connector to the motherboard to connect the CPU power connector. Under Selected Component, drag the 20+4 pin connector to the motherboard to connect the motherboard main power connector. Install the power supply as follows: From the Shelf, drag the power supply to the area in the case below the motherboard. Repeat steps 1g-1h for each power supply. Under Selected Component, examine each of the power connectors looking for all of the connectors required for this scenario. Select the Specifications tab to determine how many pins the main motherboard and the CPU power supply require. Under Selected Component, select Details to identify the existing connectors for the motherboard.

Select the motherboard to view the documentation. Complete this lab as follows: Install a power supply as follows: Above the computer, select Motherboard to switch to the motherboard view. Start the computer and boot into Windows. Plug the computer in using the existing cable plugged into the power strip. Connect the power connector for the optical drive. Connect the power connectors for the SATA hard drives. Make the following connections from the power supply: Connect the motherboard power connector. Make sure the power supply you select will support adding a graphics card that requires its own power connector. Install a power supply based on the following requirements: The power supply must have the appropriate power connectors for the motherboard and the CPU.
